Hastelloy B2 Fasteners

UNS N10665 Fasteners, DIN 2.4617 Fasteners

We are Manufacturer, Supplier & Exporter of Hastelloy B2 Fasteners (N10665), Hastelloy B2 Fasteners in various sizes, dimensions and standards at market leading prices. These Fasteners are available from Stock M3 – M56 | 3/6″ to 2″ | Custom Sizes in various Standerds as Hastelloy B2 Bolts, Hastelloy B2 Washers, Hastelloy B2 Nuts, Hex Bolts, Studs, Heavy Hex Nuts, Screw. If you do not find the size you are looking for or if you need Other Type of Fasteners please do contact us [email protected] .

Specification Of Hastelloy C276 Fasteners

Standard ASTM B335, ASME SB335
Size M 02 to M 33
Length 3 mm to 200 mm
Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard: DIN, ISO, JIS, GB, IS, BS, ASTM, ANSI – American National Standards Institute
  • ANSI B 18.2.4 2M
  • ANSI B 28.2.4 1M
  • Stud Bolt length are defined in ASME B16.5 standard
  • Hex nuts are defined in ASME B18.2.2
  • ASME B18.5
  • BS en iso 3506

DIN: DIN 931, DIN 933, DIN 934, DIN 970

UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF

ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards
Scope of Manufacturer
  • Up to M36 / 1-1/2” Dia, up to 1100mm lg
  • CNC Machined Fasteners, up to M100 / 4” Dia, up to 1500mm lg
Dia M6 to M64 (1/4" - 2.5")
Length 12 MM - 500 MM (Upto 20 Inch)
IS 1363, 1364
DIN 931, 933
ISO ISO 3506
Form of: Hex, Square, Round, Threading as per Gauge Etc.
Head Drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Finishing: Zinc (yellow, white, blue, black), black oxide, , Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Passivated, Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Mechanically Applied coating and some special one like DACROMET
Production Process M2-M24: Cold Froging, hot forging M24-M100, , machining and CNC for Customized connecting element
Types Nuts, Bolts, Screws, Socket Screw, Sockets, Studs, Screw, Nut, Spring Washers, Hex Set Screw, Socket Hexagon Head Screw, Cap Screw, Wing Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Studs, Anchors, Hex Nut,Marine Anchors, Hexagon Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Anchor Bolt, U- Bolts, J Bolts, T-Head Bolts, Mushroom Head Square Neck Bolts, Eye Bolt, Foundation Bolts, Structural Bolts

Equivalent Grades

STANDARD UNS WERKSTOFF NR.
Hastelloy B2 N10665 2.4617

Chemical Composition

Hastelloy B2 Ni C Mo Mn Si Fe P S Co Cr
Balance 0.02 max 26.0-30.0 1.0 max 0.10 max 2.0 max 0.040 max 0.030 max 1.0 max 1.0 max

Mechanical Properties

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
9.2 g/cm3 1370 °C (2500 °F) Psi – 51,000, MPa – 350 Psi -1,10,000, MPa -760 40 %
