Inconel 625 Fasteners

UNS N06625 Fasteners, DIN 2.4856 Fasteners

We are Manufacture, Suplier & Export of Inconel 625 Fasteners that are actually manufactured from High Quality of Standard Raw Materials and are designed as per with national and international standards. Alloy 625 fasteners have exceptional resistance to crevice corrosion and stress corrosion cracking, as well as chemical attack under highly oxidizing to moderately reducing conditions. UNS N06625 Fasteners is frequently used in chemical processing, oil & gas, naval and aerospace industries. From cryogenic temperatures, Inconel 625 Fasteners (UNS N06625) can be functioned up to 645 Degree F (340 Degree C).

Inconel 625 screws have high strength and resistance to cryogenic temperatures up to 1093 degrees C (2000 degrees F). Inconel Alloy 625 Fasteners ability to hold out extraordinary stress and a comprehensive range of heats, both in & out of water, besides being able to repel corrosion while exposing to very much acidic environments forms it a suitable choice for marine and nuclear applications.

Specification Of Inconel Alloy 625 Fasteners

Standard ASTM B446, ASME SB446
Size M 02 to M 33
Length 3 mm to 200 mm
Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard: DIN, ISO, JIS, GB, IS, BS, ASTM, ANSI – American National Standards Institute
  • ANSI B 18.2.4 2M
  • ANSI B 28.2.4 1M
  • Stud Bolt length are defined in ASME B16.5 standard
  • Hex nuts are defined in ASME B18.2.2
  • ASME B18.5
  • BS en iso 3506

DIN: DIN 931, DIN 933, DIN 934, DIN 970

UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF

ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards
Scope of Manufacturer
  • Up to M36 / 1-1/2” Dia, up to 1100mm lg
  • CNC Machined Fasteners, up to M100 / 4” Dia, up to 1500mm lg
Dia M6 to M64 (1/4" - 2.5")
Length 12 MM - 500 MM (Upto 20 Inch)
IS 1363, 1364
DIN 931, 933
ISO ISO 3506
Form of: Hex, Square, Round, Threading as per Gauge Etc.
Head Drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Finishing: Zinc (yellow, white, blue, black), black oxide, , Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Passivated, Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Mechanically Applied coating and some special one like DACROMET
Production Process M2-M24: Cold Froging, hot forging M24-M100, , machining and CNC for Customized connecting element
Types Nuts, Bolts, Screws, Socket Screw, Sockets, Studs, Screw, Nut, Spring Washers, Hex Set Screw, Socket Hexagon Head Screw, Cap Screw, Wing Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Studs, Anchors, Hex Nut,Marine Anchors, Hexagon Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Anchor Bolt, U- Bolts, J Bolts, T-Head Bolts, Mushroom Head Square Neck Bolts, Eye Bolt, Foundation Bolts, Structural Bolts

Equivalent Grades

Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
Inconel 625 N06625 NA 21 NiCr22Mo9Nb 2.4856 NC22DNB4M ХН75МБТЮ NCF 625

Chemical Composition

Grade C Mn Si Fe S Cr2 Al-Ti Ni
625 min. – – – – – 20.0 – 58.0
max. 0.10 0.50 0.50 5.0 0.015 23.0 0.40 –

Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
625 Psi – 1,35,000 , MPa -930 Psi – 75,000 , MPa – 517 42.5 – –


Application Industries

  • Hydrogenators
  • Lab Autoclaves
  • High Pressure Reactors
  • Agitators
  • Catalyst Filers
  • Mini Magnetic Coupling
