Hastelloy C22 Pipe Tubes

UNS N06022 Pipes, DIN 2.4602 Pipes

We are Manufacturer, Supplier & Exporter of Hastelloy Alloy C22 Pipes and Tubes, which work hardens more readily than most austenitic stainless steels. Due to its excellent content, Hastelloy C22 Tubes exhibits excellent resistance to both oxidising and reducing acid environments as well as those containing mixed acids. The precise smooth bore Hastelloy C22 Pipes and tubes are the most suitable ones for bleaching operations, brackish water, closed loop water systems, some food processing units and certain other marine environments. It has poor corrosion resistance to oxidizing environments, therefore, it is not recommended for use in oxidizing media or in the presence of ferric or cupric salts because they may cause rapid premature corrosion failure. Hastelloy C22 Seamless Pipes is a nickel – chromium – molybdenum alloy with enhanced resistance to pitting, crevice corrosion and stress corrosion cracking. Hastelloy C22 Welded Pipes are known throughout the world as the premier corrosion – resistant alloys. We offer these UNS N06022 Pipes and Tubes in international and national quality of standards at cost-effective rates to our patrons. It offers stress-corrosion cracking, crevice corrosion and resistance to pitting.

We are Manufacturer & Supplier of Hastelloy C22 Pipe & Tubes in India. These Pipe Seamless / Welded are available from 1/4"(13.72mm) NB x Sch10/10s(1.65mm)  wall to 6"(168.28mm) NB x Sch40/40s(7.11mm) wall in various lengths from stock. If you do not find the size you are looking for or if you need Other Size of Pipe & Tubes please do contact us [email protected] .

Specification Of Hastelloy C22 Pipes & Tubes

C22 Pipes Specifications ASTM B622, B517, B163, B516 / ASME SB622, SB517, SB163, SB516
Dimensional specification ANSI/ASME B36.19M, ANSI/ASME B36.10M
ASTM B622 B163 C22 Seamless Pipe & Tube Size 1 / 2" NB - 16" NB
ASTM B622 B163 C22 Welded Pipe & Tube Size 1 / 2" NB - 24" NB
ASTM B517 B516 C22 EFW Pipe & Tube Size 6" NB - 24" NB
Outside Diameter 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Hastelloy C22 Pipes & Tubes Manufacturing Shapes Hydraulic, Round, Rectangle, Square, Hex, Honed
Hastelloy C22 Pipes & Tubes Manufacturing Techniques Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Hastelloy C22 Pipes & Tubes Schedule Thickness Range SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Hastelloy C22 Pipes & Tubes End Types Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends)
Delivery Condition of Hastelloy C22 Pipes & Tubes Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Surface Finish No.1, No.4, No.8 Mirror Finish, 2B
Value Added Services Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing
Inspection and Test Reports EN 10204 3.1, Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports
Marking Specification
Grade
Nominal Pipe Sizes
Pipe Schedule or Wall Thickness
Manufacturing Method (Seamless / Welded)
Heat Number
Manufacturer’s Name or Custom Logo - on request
Marked Pipe Sample: ANSI B36.19 ASTM A 312 TP 600 12" NB SCH 40S SEAMLESS HEAT NO. XXXX
Outside Finish 2B, No.4, No.1, No.8 Mirror Finish for Inconel Pipes, Finish as per customer Requirements
Delivery Condition Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Packing of Hastelloy C22 Pipes & Tubes Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials Sizes and Specifications other than above can be on request

Equivalent Grades

STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
Hastelloy C22 N06022 2.4602 NiCr21Mo14W NW 6022

Chemical Composition

Hastelloy C22 Ni C Mo Mn Si Fe P S Co Cr
Balance 0.010 max 12.5 – 14.5 0.50 max 0.08 max 2 – 6 0.02 max 0.02 max 2.5 max 20 – 22.5

Mechanical Properties

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.69 g/cm3 1399 °C (2550 °F) Psi – 45000 , MPa – 310 Psi – 1,00,000 , MPa – 690 45 %


Application Industries

  • Hydrogenators
  • Lab Autoclaves
  • High Pressure Reactors
  • Agitators
  • Catalyst Filers
  • Mini Magnetic Coupling
