Inconel 925 Pipe Fittings

UNS N08825 Pipe Fittings

We are Manufacturer, Supplier & Exporter of Incoloy 925 Pipe Fittings (UNS N08825), Incoloy 925 Fittings in various sizes, dimensions and standards at market leading prices. These Pipe Fittings are available from Stock 1/2″ – 10″ in various schedules as Incoloy 925 Elbow, Incoloy 925 Eccentric & Concentric Reducer, Incoloy 925 Stub End, Long & Short Radius Elbow, Pipe End Cap. If you do not find the size you are looking for or if you need Other Type of Pipe Fittings please do contact us [email protected] .

Specification Chart of Incoloy 925 Pipe Fittings

Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size Seamless Fittings : 1/2" - 10"
Welded Fittings : 1/2" - 48"
Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D
Size Range ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Connection Welding
Manufacturing Process Push, Press, Forge, Cast, etc.
Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Specialized Manufacturer of 90 Deg. Elbows, 45 Deg. Elbow, Tee, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend

Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS
Incoloy 925 – N09925 NCF 925

Chemical Composition

Grade C Mn Si S Cu Fe Ni Cr Al Ti
925 0.03 max 1.00 max 0.05 max 0.03 max 1.50 – 3.00 22.00 min 42.00 – 46.00 19.55 – 22.50 0.01-0.05 max –

Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
925 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %
